microcomputer controlled heat sealing and cutting machine
microcomputer controlled heat sealing and cutting machine Details：
RFQ series is my computer bag making machine plastic packaging company for the needs of the market, research System developed a keen edge sealing bag equipment, supporting the use of the same film can be folded on the OPP, PP , PE, shrink film of plastic material for sealing and cutting bag. Models based on its configuration and function of different sub- As Class II (see below). The products are widely used in clothing, stationery, hardware and other products Packaging. The machine set machine, electricity, gas as a whole, the use of advanced single-chip microcomputer as the master, together with the step Type fixed-length, optical scan tracking, temperature controlled, air drilling and other industrial equipment to the production of packages Packaged product size precision, sealed solid line, tangent and beautiful that you can be assured of quality equipment bag. When you order, please read the menu below to choose the model you need.
microcomputer controlled heat sealing and cutting machine Technical parameters：
Basic instructions RFQ350/800 PC computer eagerly looking machine RFQ500/800 Multifunctional Machine Basic specifications for bag material folded film forming OPP, PE, PP, folded shrink film forming OPP, Jane profiles PE, PP, shrink film
Effective width of bag 500,700 mm 500,700 mm
The effective length of the bag 50 ~ 1000mm 500 ~ 1000mm
Accuracy of ± 0.5mm ± 0.5mm
Bag Mechanical speed 200pcs/min 200pcs/min
Power supply AC 220V or AC380V AC single-phase single-phase 220V or AC380V
Machine spare power 4kw 5kw
Frame in the form of unwinding duplex cone solid fan-style duplex cone solid fan-type (LPC correction discharge device) Coil diameter Ф500mm Ф500mm Tension way manual manual mechanical mechanical friction Friction (optional magnetic particle brake) Feeding Mode DC motor speed control, arm type feeding DC motor speed control, arm type feeding Mechanical power main motor 0.75kw 0.75kw inverter motor variable frequency motor Transmission pulley pulley Fixed length correctly predicted a long way to pull the stepper motor system, computer-controlled stepper motor and computer control (optional servo motor) Optical inspection mark switch Photoelectric Switch Photoelectric mark Seal bag features the form of sliced, sliced fancy point, the point of fancy Tube-type materials can be made open edge to open edge, insert the end of M, envelope-style Article is not on the stickers, punch-line stickers on the article, Ф6mm single stickers on the aircraft punched holes article, Ф6mm aircraft Hole Punch Temperature 0 ~ 400 ℃ cutter way of digital temperature controller 0 ~ 400 ℃ digital temperature controller Roller compacted 0 ~ 300 ℃ temperature control pointer Optional features to import or distribution control electrical components imported from Taiwan or Taiwan
|
