TY based desktop folding machine
Details
The device is a multifunction device, you can fold the plastic film, roll flowers, lined pearl film, M pinch the end of two-fold, such as wallet bag, leather books, etc., to produce finished no scratches, smooth and beautiful, the operation convenience, the advantages of high speed and stable.
Technical parameters
Project TZB-600 TZB-800
Coil size diameter Ф500mm
Maximum width of 1000mm
Diameter Ф600mm
Maximum width of 1200mm
Fold top speed of 80m/min
Winding diameter Ф450mm
0.018 ~ 0.08mm thickness
Folding accuracy ± 0.5mm
Total power 2kw
Gas source 0.6Mpa
Weight 600kg 800kg
Dimensions 5350 × 1800 × 1450mm 5350 × 2000 × 1500mm
|
